Commercial spaces are rarely built the same way. A retail store may have floor-to-ceiling glass with limited wall space. A restaurant may want its HVAC system hidden from customers. An open office or studio may need air distributed across a larger shared area.

That is why choosing a commercial HVAC system should be about more than capacity alone.

The new TOSOT Light Commercial HVAC Series introduces three indoor unit configurations designed around different commercial environments: Floor/Ceiling, Concealed Ducted, and Ceiling Cassette.

Across the lineup, TOSOT combines flexible installation, ENERGY STAR® certified efficiency, and extreme-climate performance, with cooling operation in outdoor temperatures up to 140°F and heating operation down to -40°F.

Floor/Ceiling: No Wall Space? No Problem.

Large windows, glass curtain walls, displays, and open interiors can leave very little room for a conventional wall-mounted indoor unit.

The TOSOT Floor/Ceiling system is designed for exactly that challenge. It supports two installation styles: mounted low near the floor or suspended from the ceiling.

This flexibility gives contractors more options when working around windows, shelving, furniture, and other architectural constraints, making it especially suitable for retail stores, showrooms, restaurants, offices, studios, and glass-front commercial spaces.

Available in 18K and 24K configurations, the Floor/Ceiling series is a practical choice when preserving usable wall space is a priority.

Concealed Ducted: Comfort Without the Clutter

When visible HVAC equipment does not fit the interior design, the TOSOT Concealed Ducted system keeps the indoor unit largely hidden above the ceiling or inside a service space. Conditioned air is distributed through ductwork and discreet supply grilles, allowing customers and employees to experience the comfort without making the HVAC equipment a visual feature.

Available in 18K and 24K capacities, the system supports high external static pressure, helping contractors accommodate longer or more complex duct layouts. Current product specifications support adjustable external static pressure up to 200 Pa. Both models also feature a built-in condensate pump, adding flexibility where gravity drainage alone may not be practical.

Installation flexibility extends beyond the indoor unit: the Concealed Ducted models support up to 82 ft of height difference between indoor and outdoor units and approximately 131 ft of maximum piping length.

For added convenience, the Concealed Ducted models feature Wi-Fi and App control, allowing users to adjust settings directly from a smartphone.

For restaurants, offices, conference rooms, and design-focused commercial renovations, it provides an effective combination of hidden installation, flexible duct design, built-in drainage support, and connected control.

Ceiling Cassette: Comfort for Open Spaces

Open commercial spaces create a different challenge: distributing conditioned air across a larger shared area.

The TOSOT Ceiling Cassette system integrates into the ceiling and delivers air in multiple directions, helping create more balanced comfort across restaurants, retail stores, open offices, studios, reception areas, and showrooms.

Because the indoor unit is installed overhead, walls remain available for shelving, merchandise, windows, artwork, and furniture.

The Ceiling Cassette lineup offers the widest capacity range, with 9K to 24K models, and efficiency reaching up to 24 SEER2. All cassette capacities also include a built-in condensate pump, helping simplify drainage in ceiling installations.

Installation range varies by capacity. The 9K, 12K, and 18K models support up to 40 ft of height difference, while the 24K model extends that capability up to 82 ft, making it more suitable for larger commercial projects with greater separation between indoor and outdoor equipment.

Compare the Three Configurations

Ready for Extreme Weather

Flexible installation is only part of the TOSOT Light Commercial Series.

The lineup is engineered for year-round performance in demanding climates, with cooling operation up to 140°F and heating operation down to -40°F.

ENERGY STAR® certification adds another important benefit for businesses focused on long-term operating efficiency, while efficiency ratings reach up to 24 SEER2 depending on model.

Together, the three configurations give contractors and business owners more freedom to choose a system based not only on capacity, but also on how the equipment fits the building.

Which Configuration Is Right for Your Space?

Choose Floor/Ceiling when walls are occupied by windows, displays, or architectural features.

Choose Concealed Ducted when HVAC should stay out of sight and the project requires greater duct-design flexibility.

Choose Ceiling Cassette when an open commercial space benefits from multi-directional airflow and integrated condensate drainage.

Different spaces create different HVAC challenges. The new TOSOT Light Commercial HVAC Series gives contractors and businesses more ways to solve them—without designing the space around the HVAC system.
